Easy and flexible to find the right finger
The FINGERKIT System 16 enables application-specific gripper fingers for compact gripper modules to be assembled from standardized components. The various elements can be combined flexibly and adapted to the workpiece and gripping task. A starter set contains all the components required to begin designing simple gripper fingers right away.
Fingerkit System 16
Starterset System 16
Item-No. 5160001
Fingerkit Starter Set, size 16. Construction kit for creation of specific gripper fingers based on standard parts. Contains a basic selection of elements to build simple gripper fingers. Suitable for IEG PLUS 40, CRG series and WPG 100.
BE 16-010
Item-No. 5150001
Fingerkit system 16, basic plate BE 16-010 for gripper modules IEG 55, IEG PLUS 40, CRG 30 as well as appropriate GRIPKITs
BE 16-015
Item-No. 5150002
Fingerkit system 16, basic plate BE 16-015 for gripper modules IEG 55, IEG PLUS 40, CRG 30 as well as appropriate GRIPKITs
BE 16-020
Item-No. 5150003
Fingerkit system 16, basic plate BE 16-020 for gripper modules IEG 55, IEG PLUS 40, CRG 30 as well as appropriate GRIPKITs
BE 16-025
Item-No. 5150004
Fingerkit system 16, basic plate BE 16-025 for gripper modules IEG 55, IEG PLUS 40, CRG 30 as well as appropriate GRIPKITs
BE 16-040
Item-No. 5150029
Fingerkit system 16, basic plate BE 16-040 for gripper modules IEG 55, IEG PLUS 40, CRG 30, WPG 100 as well as appropriate GRIPKITs
AC 16-020
Item-No. 5150008
Fingerkit system 16, angle connector AC 16-020 for gripper modules IEG 55, IEG PLUS 40, CRG 30, WPG 100 as well as appropriate GRIPKITs
FE 16-020
Item-No. 5150005
Fingerkit system 16, finger element FE 16-020 for gripper modules IEG 55, IEG PLUS 40, CRG 30, WPG 100 as well as appropriate GRIPKITs
FE 16-030
Item-No. 5150006
Fingerkit system 16, finger element FE 16-030 for gripper modules IEG 55, IEG PLUS 40, CRG 30, WPG 100 as well as appropriate GRIPKITs
FE 16-050
Item-No. 5150007
Fingerkit system 16, finger element FE 16-050 for gripper modules IEG 55, IEG PLUS 40, CRG 30, WPG 100 as well as appropriate GRIPKITs
TE 16-040
Item-No. 5150009
Fingerkit system 16, T-element TE 16-040 for gripper modules IEG 55, IEG PLUS 40, CRG 30, WPG 100 as well as appropriate GRIPKITs
TE 16-060
Item-No. 5150010
Fingerkit system 16, T-element TE 16-060 for gripper modules IEG 55, IEG PLUS 40, CRG 30, WPG 100 as well as appropriate GRIPKITs
DP 16-005
Item-No. 5150011
Fingerkit system 16, spacer plate DP 16-005 for gripper modules IEG 55, IEG PLUS 40, CRG 30, WPG 100 as well as appropriate GRIPKITs
FT 16-CR
Item-No. 5150025
Fingerkit system 16, grip insert FT 16-CR for gripper modules IEG 55, IEG PLUS 40, CRG 30, WPG 100 as well as appropriate GRIPKITs
FT 16-UNI
Item-No. 5150026
Fingerkit system 16, universal grip insert FT 16-UNI for gripper modules IEG 55, IEG PLUS 40, CRG 30, WPG 100 as well as appropriate GRIPKITs
